4.5 Quality Management
To monitor all the outputs of a particular category (PPS, for example) simultaneously:
1.
Navigate to INTERFACES > OUTPUTS , and click the desired output category (
e.g., PPS Output ):
2.
The Status window will display a list of all outputs of the selected category:
To display more detailed information about a particular output, click the corresponding
INFO button.
To edit the settings of a given output, click the GEAR button (see also "Configuring Out
puts" on page 131.)
To refresh the information displayed, click the REFRESH button (circling arrows icon).
In the illustration of the rear panel, click on a connector to highlight the corresponding
list entry.
Displaying the settings of a specific output
The outputs installed in your SecureSync unit have specific settings that can be reviewed, and—
to some extent—edited.
To display the settings of an output:
1.
Navigate to INTERFACES > OUTPUTS , and click on the desired output (recessed e.g., PPS Out
put 0 ):
