Figure 5-8:
b.
Using the supplied cable ties, secure the coax cable from the option card to the white
nylon cable tie holders fastened to the mainboard.

5.2.2.11 [8]: Gb ETH Card Installation, Slot1 Empty

Installation of the Gigabit Ethernet module card (PN 1204-06), if Slot 1 is empty:
Note:
card already installed in Slot 2, that card must be relocated to a different slot.
a.
Safely power down the SecureSync unit and remove the chassis cover. Save the screws.
c.
Remove the blank option card plate, or the existing option card. Save the screws.
SecureSync User Reference Guide
J Connectors
Note: For 10 MHz option cards with 3 coax cables: From the rear of the
option card, outputs are labeled J1, J2, J3. Start by connecting the cable
attached to J1 on the card to the first available open connector on the
SecureSync mainboard, then connect the cable attached to J2, then J3, etc.
The Gigabit Ethernet option card must be installed in
b.
Caution: NEVER install an option card from the rear of the unit, ALWAYS
from the top, after removing the chassis cover.
APPENDIX
. If there is a
Slot 2
