Output Port: Pin Assignments
Table 5-25:
Pin Number
Top row of 5 pins
1
2
3
4
5
Bottom row of 4 pins
6
7
8
9
Viewing the State of Event Broadcast and Event Input
To view the Status of Event Broadcast and Event Input, see "Viewing an Input/Output Signal
State" on page 331.
Event Broadcast Output: Edit Window
To configure the Event Broadcast Output , go to its Edit window. For instructions, see: "Con
figuring Option Card Inputs/Outputs" on page 330.
The Web UI list entry for this card is: Event Broadcast .
480
Output connector DB-9: pin-out
Signal Name Function
NC No Connection
SERIAL_OUT_TX RS-232 Transmit data
SERIAL_OUT_RX RS-232 Receive data
NC No connection
GND Ground
NC No connection
NC No connection
NC No connection
NC No connection
Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out
puts start at 1, because of the built-in outputs).
