Programmable Phase Shift : ±5ns to 500 ms with 5ns resolution
Maximum Number of Cards : 6
Ordering Information : 1204-28: 1PPS 1-input/3-output, BNC connectors
Figure 5-19:
Model 1204-28 option card rear plate
Model 1204-2A 1PPS Input/Output: Specifications
Inputs/Outputs : (1) 1PPS input/(2) 1PPS output
Operating Wavelength : 820/850 nm
Optical Input Minimum Sensitivity : -25 dBm @ 820 nanometers
Optical Output Power : -15 dBm average into 50/125 fiber
Fiber Optic Compatibility : 50/125 μm, 62.5/125 μm multi-mode cable
Optical Connector : ST
Output Programmable Pulse Width : 100 ns to 900 ms with 20 ns resolution
Output Absolute Phase Error : ±50 ns (1σ)
Output Programmable Phase Shift : ±5ns to 500 ms with 5ns resolution
Maximum Number of Cards : 6
Ordering Information : 1204-2A: 1PPS 1-in/2-output, ST connectors
Figure 5-20:
Model 1204-2A option card rear plate
