APPENDIX
STANAG In [1204-1D, -24]: Specifications
Inputs : (2) STANAG Inputs, (1) 1PPS Input
Signal Type and Connector : TTL or RS-485 level (user selectable) for STANAG and 1PPS
input. DB25.
Formats Supported :
Accuracy : 100 ns
Maximum Number of Cards : 6
Ordering Information : 1204-1D (for non-isolated board); 1204-24 (for isolated board)
Figure 5-44:
Figure 5-45:
422
STANAG 4246 HAVE QUICK I
STANAG 4246 HAVE QUICK II
STANAG 4372 HAVE QUICK IIA
STANAG 4430 Extended HAVE QUICK
STANAG 4430 Standard Time Message (STM)
ICD-GPS-060A BCD Time Code
ICD-GPS-060A HAVE QUICK
DOD-STD-1399 BCD Time Code
Model 1204-1D option card rear plate
Model 1204-24 option card rear plate
