Spectracom SecureSync 1200 User Reference Manual page 139

3.
4.
When the NTP Anycast Expert Mode window is opened, the files displayed are the con
figuration files in their current states. If no configuration was done outside of Expert Mode,
these will be the factory default files. If Anycast configuration was already done from the Web
UI, you will be able to edit the existing Anycast setup.
When editing
interface line is an
face), and that the next line is an
one for the interface). No other lines or variations in spacing should be inserted before or
between these lines. No editing restrictions exist on
Example zebra.conf file with both IPv4, and IPv6 configured on the same port:
(Interface eth0 line, followed by IPv4 line and then IPv6 line)
*****************************************************
!
interface eth0
ip address 10.2.100.157/16
ipv6 address 2000:10:2::157/64
!
interface lo
ip address 10.10.14.1/32
ipv6 address 2000:10:10::1/64
*****************************************************
Example zebra.conf file with IPv4, and IPv6 configured on different ports:
(Interface eth0 line, followed by only IPv4 line, because no IPv6 address is configured on that
port. Interface eth1 line, followed by only IPv6 line, because no IPv4 address is configured on
that port)
*****************************************************
!
interface eth0
ip address 10.2.100.157/16
interface eth1
ipv6 address 2000:10:2::157/64
!
interface lo
CHAPTER •
2 SecureSync User Reference Guide Rev. 23
Once it is enabled, click NTP Anycast in the Actions Panel . The Expert mode window
will appear, with a separate tab for each of the three configuration files.
To enable OSPF IPv4 Anycast, check Enable under the OSPF tab. To enable OSPF IPv6
Anycast, check Enable under the OSPF6 tab. To enable BGP Anycast, check Enable
under the BGP tab. Then click Submit.
in expert mode, you should ensure that the first line under an
zebra.conf
ip address
line declaring an IPv4 address (if there is one for the inter
line declaring an IPv6 address (if there is
ipv6 address
ospfd.conf
2.15 Configuring NTP
or files.
ospf6d.conf
123
