MM Minutes (00-59)
SS Seconds (00-60)
The leading edge of the first character (
The time synchronization status character (
? When the receiver is unable to track any satellites and the time synchronization lamp is red.
* When the receiver time is derived from the battery backed clock or set manually through the Setup Port
Interface.
E x a m p l e :
FRI 20APR15 12:45:36
The example data stream provides the following information:
Sync The clock is not time synchronized to GNSS. Time is derived from the battery backed clock or
Status set manually.
Date Friday April, 23, 2015
Time 12:45:36
5.4.7

Spectracom Format 2

This format provides a time data stream with millisecond resolution. The Format 2 data stream
consists of indicators for time synchronization status, time quality, leap second and Daylight
Saving Time. Time data reflects UTC time and is in the 24-hour format. Format 2 data structure
is shown below:
Note:
Daylight Saving Time adjustment. Attempting to configure a Local clock using
Data Format 2 with either a Time Zone Offset or automatic DST rule will result in
an error message.
E x a m p l e
CR LF IQYY ^ DDD ^ HH:MM:SS.SSS ^ LD
Where:
SecureSync User Reference Guide
) marks the on-time point of the data stream.
CR
) is defined as described below:
I
Format 2 cannot be configured for a Time Zone Offset or with automatic
m e s s a g e :
APPENDIX
503
