2.1 Overview
2.1

Overview

This section provides an outline of the steps that need to be performed prior to putting
SecureSync into service. This includes:
Installation
Setup
("Web UI").
Configuration
protocols (e.g., NTP), other settings.
The following factors determine which steps need to be taken:
a.
The power source(s) your SecureSync is configured for.
b.
Your existing infrastructure and how you plan on integrating SecureSync into it (for
example, integrating it into an existing Ethernet network, or setting-up a standalone
installation.)
c.
How you would like to setup basic network configuration parameters:
d.
The option cards configuration of your unit: Is your SecureSync equipped with any
option cards, such as additional input references, or additional signal distribution
cards? If so, they need to be configured separately via the SecureSync Web UI, once
the network configuration is complete.
2.1.1

Main Installation Steps

The following list is a recommendation. Deviations are possible, depending on the actual
application and system configuration.
1.
Unpack the unit, and take inventory: "Unpacking and Inventory" on the facing page.
2.
Obtain required tools and parts: "Required Tools and Parts for Installation" on page 32.
3.
Mount the unit: .
4.
Read the Safety instructions: "SAFETY" on page 33.
5.
Connect your power supply/-ies: "Connecting Supply Power" on page 37.
30
: Hardware setup, mechanical installation, physical connections.
: Establish basic access to the unit, so as to allow the use of the web user interface
: Access the Web UI, configure the network, input and output references,
Using the unit's front panel keypad and information display
Using a PC connected to SecureSync via serial cable
Using a PC connected to SecureSync via network cable.
You can connect your PC to SecureSync either...
...directly by means of a dedicated Ethernet cable, or
...indirectly, using your existing Ethernet network (using a network hub).
CHAPTER •
2 SecureSync User Reference Guide Rev. 23
