The NTP Servers window opens. Should the list be empty, no servers have been added
yet. In the event that added servers are not displayed in the NTP Setup screen/NTP Serv
ers panel, they could not be resolved. Verify the IP address. Note that System servers can
not be edited or deleted.
To ADD a new server, click the PLUS icon in the upper right-hand corner, and pro
ceed to the next step.
Note: In order for other NTP Servers to be a valid reference, "NTP"
must be enabled as both the Time and 1PPS references in the Refer
ence Priority table. See
page 157.
To EDIT an existing server, click the corresponding ACTION GEAR button, and
proceed to the next step.
To REMOVE a server (and its associated configurations), click the X-button next to
it, then confirm by clicking OK.
The NTP Server Edit window displays. Enter the required information:
Host : The IP address for the server to be used as host.
Min Poll Interval : Select a value from the drop down (the default is 3 (8s)).
Max Poll Interval : Select a value from the drop down (the default is 3 (8s)).
For both NTP Peers, and NTP Servers the Minimum and Maximum Poll rate for
NTP packets can be configured. Both NTP Peers and NTP Servers support either
manually configured Symmetric Key-ID/Key string pairs or the use of Auto-Key.
However, these choices are mutually exclusive and must be identically configured
on both the SecureSync and the NTP Peer or NTP Server. If the Symmetric Key-
ID/Key string pair method is selected the Key-ID must be first defined on the Sym
metric Key page.
Enable Symmetric Key : Click to enable Symmetric Key, and then select an option
from the drop down menu that displays.
Note: Before you can choose an option in the
first set up symmetric keys through the
figuring NTP Symmetric Keys" on
check the
Enable Autokey : Click here if you want to use Autokey with this server. See "NTP
Autokey" on page 106.
"Configuring Input Reference Priorities" on
page 112. Conversely, you may
box below the
Autokey Key
2.15 Configuring NTP
Key field, you must
Actions panel. See "Con
field.
