2.16

Configuring Input References

Depending on the type of input reference, some of its settings may be user-editable. To access
these settings for a given input reference, choose one of the two methods described below.
There are two ways to access the settings Status window for an input reference:
Configuring input reference settings, method 1:
1.
Under INTERFACES > REFERENCES , click the desired reference.
2.
The Status window for the specific reference you selected will be displayed. Click the Edit but
ton in the bottom-left corner.
3.
The settings window for the chosen reference will be displayed. Edit the field(s) as desired.
Configuring input reference settings, method 2:
1.
In the INTERFACES > REFERENCES drop-down menu, click REFERENCES (white on orange), or
an input reference category ("GNSS reference", for example).
2.
In the Status window, click the GEAR button next to the desired input reference.
3.
The settings window for the chosen reference will be displayed. Edit the field(s) as desired.
2.17

Configuring Outputs

Depending on the type of output interface, some of its settings may be user-editable. To access
these settings for a given output, choose one of the two methods described below.
Editing output settings, method 1:
CHAPTER •
2 SecureSync User Reference Guide Rev. 23
The illustrations shown below are examples. The windows displayed in
Note:
your Web UI may look differently.
Note: A particular option card might have more than one setting that can be
adjusted. See "Option Cards Overview" on page 10
ticular output or card.
Note: The illustrations shown below are examples. The windows displayed in
your Web UI may look differently.
2.16 Configuring Input References
for the settings of any par
131
