APPENDIX
These option cards can be used for a variety of applications requiring programmable fre
quency outputs. The RS- 485 model of this card can be operated as an N.8 frequency syn
thesizer.
Depending on your card model number, the outputs are available in different formats:
RS-485 on a pluggable terminal block
TTL square wave on BNC, or
Sine wave on BNC
Each output can be phase-offset between 0-360° in 0.1°-increments.
Programmable Frequency Card 1204-13 (Sine Wave, BNC): Specifications
Outputs : (4) independently programmable sine wave outputs
Signal Type : +13 dBm
Wave Form : sine
Connector : BNC
Output Load Impedance : 50 Ω
Output Pulse/Frequency Rates : 1Hz to 25 MHz in 0.1-Hz increments
Accuracy : Function of input synchronization source (GPS, IRIG, 1 PPS, etc.)
Synchronization : Output frequency locked to SecureSync disciplined 10 MHz
Jitter , cycle-to-cycle: n/a
Phase Noise :
Harmonics : <-30 dBc
Spurious : <-60 dBc
Maximum Number of Cards : 6
Ordering Information : 1204-13, Programmable Frequency Card, sine wave, BNC
372
-120 dBc/Hz @ 1kHz offset
-130 dBc/Hz @ 10-kHz offset
-140 dBc/Hz @ 100-kHz offset
