Pin Num
Signal
ber
1
PPS_OUT
2
SERIAL_
OUT_TX
3
SERIAL_IN_
RX
4
NC
5
GND
Bottom row of 4 pins
6
NC
7
NC
8
NC
9
NC
Pin Assignments: INPUT connector J2
Figure 5-51:
INPUT connector J2
Table 5-22:
Pin-out, INPUT connector "J2"
Pin Number
Top row of 5 pins
1
PPS_IN
2
SERIAL_IN_RX
3
NC
4
NC
SecureSync User Reference Guide
Function
1PPS output
TTL level on 50 Ω
RS-232 Transmit
Data output (ToD messages)
data
RS-232 Receive
Data input into unit; use this to transmit commands
data
to the unit)
No connection
Ground
No connection
No connection
No connection
No connection
Signal
Function
1PPS input
RS-232 Receive data
No Connection
No connection
Notes
Notes
Data input into unit; ToD message
