4.5 Quality Management
The reference window being displayed will show additional status information and
option-card specific settings. The type of input reference, and the option card model
determine which status information and option card settings will be displayed.
See "Option Cards Overview" on page 10 to learn more about the different settings of
available input reference option cards.
To change settings, click the Edit button in the bottom left corner.
4.5.1.4

Reference Monitoring

Reference monitoring enables you to assess the quality of your references by comparing them
against the current system reference, and against each other. This allows you to predict or
understand system behavior in the event that the current system reference will be lost, or was
lost, respectively. You may also decide to alter reference priorities as a result of monitoring
their quality e.g., assigning a lower reference priority to a noisy reference, or a reference with
a significant offset.
SecureSync allows Reference Monitoring by comparing the phase data of references against
the System Ontime Point. The phase values shown are the filtered phase differences between
each input reference 1PPS and the internal disciplined 1PPS.
The data is plotted in a graph in real-time. The plot also allows you to display historic data,
zoom in on any data range or on a specific reference. A data set can be exported, or deleted.
To monitor the quality of references:
