TOD Format : The user-selectable format being used. Available formats include:
Electrical Format : Selects signaling on either RS-485 or TTL (supporting up to 10 V
levels) signal lines.
Time Scale : Used to set the desired time scale (UTC, TAI, GPS, or Local). See above.
Offset (ns) : Provides the ability to account for STANAG Line (TOD1 and TOD2 inde
pendently) cable delays or other latencies in the STANAG output. Available Offset range
is –500 to +500 ms in 5ns steps.
STANAG TFOM : The Time Figure of Merit for the output.
Under 1PPS Output , the following settings are displayed:
PPS Signature Control : Indicates whether the signal will be present. This function allows
the modulation to stop under certain conditions, see "Signature Control" on page 136.
PPS Offset (ns) : Used to account for 1PPS cable delays or other latencies in the 1PPS out
put. Available Offset range is –500 to +500 ms in 5ns steps.
PPS Edge : Indicates whether the output signal is a rising or falling edge pulse.
PPS Pulse Width : Indicates the Pulse Width of the 1PPS output. The Pulse Width is
entered and displayed in nanoseconds (the default Pulse Width is 200 ms).
PPS Electrical Format : Indicates signaling on either RS-485 or TTL (supporting up to 10 V
levels) signal lines.
5.2.5.4
STANAG In [1204-1D, -24]
The STANAG Input option cards 1204-1D and 1204-24 STANAG provide (2) configurable
STANAG inputs and (1) 1PPS input for the SecureSync platform.
SecureSync User Reference Guide
STANAG 4246 HQI
STANAG 4246 HQII
STANAG 4372 HQIIA
STANAG 4430 STM
STANAG 4430 XHQ
ICD-GPS-060A BCD
ICD-GPS-060A HQ
DOD-STD-1399 BCD
APPENDIX
421
