5.2.4

Telecom Option Cards

This section contains technical information and Web UI procedures relevant to SecureSync
option cards commonly used in the telecommunications industry.
5.2.4.1

T1/E1 Out [1204-09, -0A]

The E1/T1 option card provide 1.544 MHz or 2.048 MHz and E1 or T1 data outputs for the
SecureSync platform. SecureSync meets G.812 Type I when installed with a Rubidium option,
and G.811 when installed with a Rubidium option and synchronized with GNSS.
