APPENDIX
4.
If you want to change any of the settings shown in the Status window, click the Edit but
ton in the bottom-left corner. The Edit window will open:
5.
Information about the configurable settings can be found in the corresponding option
card section, see "Option cards listed by their ID number" on page 14.
5.2.1.3

Configuring Option Card Inputs/Outputs

The configurable settings of any SecureSync input or output interface are accessible through
the Edit window of the option card to which the input or output belongs. The Edit window can
be accessed in several ways; the procedure below describes the standard way:
1.
Identify the name of the card, (e.g., PPS OUT, 4-BNC ), and verify the name of the input
or output you want to configure (e.g., PPS Output 1 ).
330 SecureSync User Reference Guide
