Pin Assignments
Pin No.
Signal
1
GND
2
TOD1+ TOD1 RS-485+ Out 15
3
NC
4
TOD2+ TOD2 RS-485+ Out 17
5
NC
6
GND
7
GND
8
NC
9
1PPS+
10
TFD
11
TOD1
12
GND
13
TOD2
Table 5-18:
Models 1204-11, -25: DB-25 pin-out
STANAG Output: Edit Window
To configure a STANAG output , go to its Edit window. For instructions, see: "Configuring
Option Card Inputs/Outputs" on page 330.
The Web UI list entries for these cards are: STANAG Out and STANAG Out, Isolated .
The outputs are named: Stanag HQ Output [number] .
Note:
puts start at 1, because of the built-in outputs).
SecureSync User Reference Guide
Function
Pin No. Signal
Ground
14
-
16
-
18
Ground
19
Ground
20
-
21
1PPS RS-485+ Out
22
Time Fault Discrete
23
TOD1 TTL Out
24
Ground
25
TOD2 TTL Out
SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out
Function
TOD1- TOD1 RS-485- Out
NC
-
NC
-
TOD2- TOD2 RS-485- Out
NC
-
NC
5 MHz Out (1204-11 Only)
NC
-
1PPS-
1PPS RS-485- Out
NC
-
GND
Ground
1PPS
1PPS TTL Out
GND
Ground
APPENDIX
415
