Fiber Optic Compatibility : 50/125 μm, 62.5/125 μm multi-mode cable
Optical Connector : ST
Accuracy : see "IRIG Output Accuracy Specifications" on page 539
Number of Cards : Up to 6
Ordering Information : 1204-27, IRIG module, Fiber Optic ST Connector
Figure 5-41:
Supported IRIG Formats
The IRIG option cards models 1204-05 and -27 support IRIG input and output formats A, B, and
G (DCLS and AM). Additionally, the cards support inputs with frequency/resolution values of
no carrier/index count interval, 1kHz/1ms, 10 kHz/0.1 ms, and 100 kHz/10 ms, as well as
IRIG input coded expressions of the fields BCD
The IRIG inputs support the following coded expression combinations for BCD
and BCD
0 – BCD
1 – BCD
2 – BCD
3 – BCD
4 – BCD
5 – BCD
The cards support synchronization with the following analog and DCLS IRIG input formats:
Provided
IRIG Code Format
A-DCLS
A000
A001
402
Model 1204-27 option card rear plate
fields:
YEAR
, CF, SBS
TOY
, CF
TOY
TOY
, SBS
TOY
, BCD , CF, SBS
TOY YEAR
, BCD , CF
TOY YEAR
Code Description
IRIG A, DCLS, BCD, CF, SBS
IRIG A, DCLS, BCD, CF
, CF, SBS, and BCD
TOY YEAR
