4.5

Quality Management

4.5.1

System Monitoring

4.5.1.1

Status Monitoring via Front Panel

When you have physical access to the SecureSync front panel, the Status LEDs and the Inform
ation Display allow you to obtain a system status overview.
For more information on the Status LEDs, see "Status LEDs" on page 6.
For more information on the Information Display, see "Configuring the Front Panel" on
page 252.
It is also possible to display the front panel information display on the Web UI: Navigate to
MANAGEMENT > Front Panel .
4.5.1.2

Status Monitoring via the Web UI

While the SecureSync front panel status LEDs provide an indication of the current operating
status of the system (see "Status Monitoring via Front Panel" above), more detailed status inform
ation can be accessed via the SecureSync Web UI , such as:
The HOME screen provides time server status information, while the TOOLS > System Monitor
screen also displays hardware status data, e.g. temperature curves:
CHAPTER •
4 SecureSync User Reference Guide Rev. 23
Time synchronization status, including references
GNSS satellites currently being tracked
NTP sync status and current Stratum level
Estimated time errors
Oscillator disciplining
Temperature monitoring
Status of outputs and presence of DC input power.
