To access the NTP Status Summary panel, navigate to MANAGEMENT > NETWORK:
NTP Setup .
The NTP Status Summary panel is at the lower left of the screen. The panel contains the
following information:
Selected Ref —The reference SecureSync is currently using.
Stratum —This is the stratum level at which SecureSync is operating.
Leap Indicator —The leap indicator bits (usually 00). See "Leap Second Alert Noti
fication" on page 150.
Delay (ms) —The measured one-way delay between SecureSync and its selected
reference.
Time Offset —This is a graphical representation of the system time offset over
time. Clicking on this graph in the NTP Status Summary panel will open a win
dow in the main panel containing a larger, more detailed view of the graph. See
"The NTP Time Offset Performance Graph" on the next page.
Offset (ms) —Displays the configured 1PPS offset values.
4.5 Quality Management
