3.3 Managing References
Under the Main tab, the following information will display:
Manufacturer/Model : The manufacturer and/or model of the GNSS receiver in your
SecureSync unit.
Validity : Status indicator lights for TIME and 1PPS signals: " On " (
valid signal, " Off " (
Receiver Mode:
Receiver Dynamics : (u-blox receivers only); see "Select a setting and click Submit." on
page 176.
Survey Progress : Real-time status:
Number of Tracked Satellites : The number of satellites currently being tracked.
Offset : As set by the user, in nanoseconds.
Antenna Sense :
Position : SecureSync's geographic position by:
Receiver Constellation : (If equipped for Multi-GNSS reception) GPS/GLONASS/Ga
lileo/BeiDou/QZSS
Client A-GPS Status : A-GPS is ENABLED and running, or DISABLED
Client A-GPS Data : External A-GPS data is AVAILABLE, or UNAVAILABLE
Identified Satellite Signal Strengths : Bar graphs for all satellites detected. Color indic
ates signal strength.
168
Note: Detailed information on the different parameters can be found in the sub
sequent GNSS topics.
red ) indicates that no valid signal is available.
Single Satellite : Used in areas with poor GNSS reception.
Standard : Default operating mode for the GNSS receiver.
Mobile : For non-stationary applications.
ACQUIRING (x Satellites)—
SURVEYING (x %)— yellow
COMPLETE — green
OK ( green )
Open : Check the antenna for the presence of an open.
Short :Check the antenna for the presence of a short.
Latitude : In degrees, minutes, seconds
Longitude : In degrees, minutes, seconds
Altitude : In meters MSL (Mean Sea Level)
red
; remains at 1% if no satellites are in view
CHAPTER •
3 SecureSync User Reference Guide Rev. 23
green ) indicates a
