4]: Bottom Slot Installation - Spectracom SecureSync 1200 User Reference Manual

Table 5-6:
Installation steps
Part No. Option Card
1204- 08
1204- 26
1204- 1C
1204- 0C
1204- 0F
1204- 06
All other Part No.'s
5.2.2.7

[4]: Bottom Slot Installation

Instructions for installing an option card into one of the three bottom slots ( 1 , 3 , or 5 ):
a.
Safely power down the SecureSync unit and remove the top cover of the main chassis
(housing). Save the screws.
b.
Remove the blank option card plate, or the existing option card in the slot. Save the
screws. If a card is populating the slot above the bottom slot your option card is to be
installed into, remove it temporarily.
c.
Insert the card into the bottom slot by carefully pressing its connector into the mainboard
connector (see Figure below), and by lining up the screw holes on the card with the
chassis.
SecureSync User Reference Guide
Installation
Card Function
Location
Frequency output Slot 2, 4, or 6 empty
Slot 1, 3, or 5 (1), 2, 3, 4, 7, 11, (12)
Alarm relay Slot 2, 4, or 6 empty
Slot 1, 3, or 5 (1), 2, 3, 4, 7, 10, 11, (12)
Gigabit Ethernet Slot 2
(miscellaneous) Slot 2, 4, or 6 empty
Slot 1, 3, or 5 (1), 2, 3, 4, 11, (12)
NEVER install an option card from the rear of the unit, ALWAYS
Caution:
from the top, after removing the chassis cover.
Bottom Slot PROCEDURE STEPS [x]
(1), 2, 3, 5, 7, 11, (12)
populated (1), 2, 3, 6, 7, 11, (12)
(1), 2, 3, 5, 7, 10, 11, (12)
populated (1), 2, 3, 6, 7, 10, 11, (12)
empty (1), 2, 3, 8, 11, (12)
populated (1), 2, 3, 9, 11, (12)
(1), 2, 3, 5, 11, (12)
populated (1), 2, 3, 6, 11, (12)
APPENDIX
337
