APPENDIX
2.
Under the Contract tab of the GB PTP Edit window, make the following settings:
5.2.7

Miscellaneous Option Cards

This section contains technical information and SecureSync Web UI procedures pertaining to
option cards that do not fall into other categories, e.g. cards that serve as signal relays.
5.2.7.1

Alarm Relay Out [1204-0F]

The Model 1204-0F Alarm Relay Option Card provides three (3) configurable relay outputs for
the SecureSync platform.
Alarm Relay Out [1204-0F]: Specifications
Inputs/Outputs : (3) three contact relay connections (NC, common, NO)
Signal Type and Connector : Terminal block
Contacts switch under max. load of 30 VDC, 2A
Contacts rated to switch: 220 VDC
Nominal Switch Capacity : 30 V, 2A
Maximum switch voltage : 220 VDC
Maximum switch power : 60 W
Maximum switch current : 2A
Breakdown voltage : 1000 VDC between contacts
472
Min Sync Interval : The minimum value of Sync interval granted by the Master
Clock. In packets per second.
Max Sync Duration : The maximum value of Sync interval granted by the Master
Clock. In seconds.
Min Announce Interval : The minimum value of the Announce interval granted by
the Master Clock. In packets per second.
Max Announce Duration : The maximum value of the Announce interval granted
by the Master Clock. In seconds.
Min Delay_Req Interval : In packets per second.
Max Delay_Req Duration : In seconds.
Max Slaves : The maximum number of slaves to be served. The 1204-32 module
can serve up to 4000 slaves (unicast contracts).
SecureSync User Reference Guide
