APPENDIX
5.2.3.4

Frequency Out [1204-08, -1C, -26, -38]

Frequency Out [1204-08, -1C, -26, -38]: Specifications
Outputs : (3) 1MHz, (3) 5MHz, or (3) 10 MHz Outputs
Signal Type and Connector :
1MHz or 5MHz Phase Noise (with OCXO or low phase noise Rubidium oscillator):
1MHz or 5MHz Phase noise (with Rubidium oscillator):
10 MHz Phase Noise (with TCXO oscillator):
10 MHz Phase Noise (with OCXO oscillator) [Numbers in brackets represent Low Phase
Noise OCXO option]:
Harmonics : -40 dBc minimum
368
(10 MHz) +13 dBm into 50 Ω, BNC, or TNC (-38)
(5MHz) +10 dBm into 50 Ω, BNC, or TNC (-38)
(1MHz) +10 dBm into 50 Ω, BNC, or TNC (-38)
-115 dBc/Hz @ 10 Hz
-130 dBc/Hz @ 100 Hz
-140 dBc/Hz @ 1kHz
-85 dBc/Hz @ 10 Hz
-110 dBc/Hz @ 100 Hz
-130 dBC/Hz @ 1kHz
-110 dBc/Hz @ 100 Hz
-135 dBc/Hz @ 1kHz
-140 dBc/Hz @ 10 kHz
-95 [-100] dBc/Hz @ 1Hz
-123 [-128] dBc/Hz @ 10 Hz
-140 [-148] dBc/Hz @ 100 Hz
-145 [-153] dBc/Hz @ 1kHz
-150 [-155] dBc/Hz @ 10 kHz
