LED Label
FAULT
1.4

Unit Rear Panel

The SecureSync rear panel accommodates the connectors for all input and output references.
Figure 1-3:
Typically, option cards will be installed at the factory. Should you purchase an extra option
card at a later point, you will need to populate the next vacant slot, observing the numerical
CHAPTER •
1 SecureSync User Reference Guide Rev. 23
Activity/Color
Off
Blinking
orange
Solid
orange
Red
Optional AC connection for the power input
Optional DC power connector
Ethernet and USB connections
1PPS output
10 MHz output
Six bays for option cards
One optional antenna connector.
Standard rear panel
Description
No alarm conditions are currently active.
A GNSS antenna alarm has been asserted and is currently active.
A short or open circuit has been detected in the GNSS antenna
cable. The light will automatically turn off once the alarm condition
clears.
To troubleshoot this condition, see
UI Status Page" on page 320
A Minor Alarm condition (other than an antenna problem alarm)
has been asserted and is currently active.
To troubleshoot this condition, see
on page 317 .
A Major Alarm condition has been asserted and is currently active.
To troubleshoot this condition, see
on page 317 .
1.4 Unit Rear Panel
"Troubleshooting via Web
.
"Minor and Major Alarms"
"Minor and Major Alarms"
