Spectracom SecureSync 1200 User Reference Manual page 473

PTP Grandmaster [-32]: Specifications
Inputs/Outputs : (1) Configurable as Input or Output
Signal Type and Connector : Ethernet via SFP, and 1PPS Output via BNC
Management : Web UI
Resolution : 8ns (±4ns) packet time stamping resolution
Accuracy : 30 ns accuracy (3σ) Master to Slave, via crossover cable
Network Speeds : 100 Mb/s, or 1Gb/s, depending on SFP module used
PTP Version supported: PTP 2 (IEEE 1588-2008)
PTP Profiles supported: Default, Telecom, Enterprise
Transmission modes : Unicast [default], Multicast
Maximum Number of Cards : 6
Ordering Information : 1204-32: PTP/Precision Timing Protocol Option Module
Figure 5-54:
Model 1204-32 option card rear plate
PTP Grandmaster [-32]: Edit Window
1.
To configure this option card, go to its Edit window. For instructions, see "Configuring
Option Card Inputs/Outputs" on page 330.
