Figure 3-54 Ivmnl/Ivmn8 - Front Panel (S30122-H7688-X -X100) - Siemens HiPath 3000 Service Manual
Hide thumbs
Also See for HiPath 3000:
- Operating instruction (176 pages) ,
- User manual (165 pages) ,
- Operating manual (154 pages)
Table of Contents
Advertisement
boards.fm
Boards for HiPath 3000
Peripheral Boards
Front panel
Two LEDs indicating the board status:
LED (green)
●
LED (yellow)
●
Lockout switch
Ethernet (10/100BaseT) interface (8-pin RJ45 jack)
Figure 3-54
IVMNL/IVMN8 - Front Panel (S30122-H7688-X -X100)
3-116
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
