CLUTCH/GEARSHIFT LINKAGE
Install the clutch outer onto the mainshaft.
NOTE:
AUgn the grooves in the clutch outer with the
bosses on the oil pump drive sprocket while turning
the sprocket with the chain and pushing the clutch
outer onto the mainshaft.
Install the thrust washer onto the mainshaft.
Coat the clutch discs and plates with engine oil.
Install the sprIng seat and judder spring to the
clutch center as shown.
End clutch disc
haslt\Stall the erid clutch disc.
a
larger /.D. than
In§tall
th,e"seven clutch plates and seven discs A,
JUDDER SPRING
disc
A. starting~wifh
the clutchplste."
Il1stallflie.pressure plate.
~DISCA
-:71
END CLUTCH DISC
11-19
