5C–14 POWER–ASSISTED BRAKE SYSTEM

Removal

1. Raise the vehicle and support it with suitable safety
stands.
2. Remove wheel and tire assembly as necessary.
3. Clean dirt, grease, and other foreign material off the
pipe fittings at both ends.
4. Remove brake pipe (1).
5. Remove plastic clip (2).

Brake Pipe

Installation

To install, follow the removal steps in the reverse order,
noting the following points.
1. Tighten the brake pipes to the specified torque.
Master cylinder and P&B valve sides
Torque: 12 N·m (104 lb in)
Others
Torque: 16 N·m (12 lb ft)
After installing the brake pipes, bleed the brakes as
described in this section.
330RW011
330RW002
