0A–2
GENERAL INFORMATION

Illustration Arrows

Arrows are designed for specific purposes to aid your understanding of technical illustrations.
Arrow Type Application
Front of vehicle
Up Side
Task Related
View Detail
View Angle
Dimension (1:2)
Sectioning (1:3)
Arrow Type
f Ambient/Clean air
flow
f Cool air flow
f Gas other than
ambient air
f Hot air flow
f Ambient air mixed
with another gas
f Can indicate
temperature change
Motion or direction
Lubrication point oil or
fluid
Lubrication point grease
Lubrication point jelly
Application
