Manage Links Dialog

The Manage Links dialog has tabs for CAD Formats, Revit models, and DWF Markups. Under the tabs are
columns that provide information about the linked file.
Column
Linked File
Status
Reference Type (Revit models only)
Locations Not Saved
Size
Saved Path
Path Type
Local Alias (Revit models only)

Link Management Options

To manage links in your file, select them in the Manage Links dialog. You can select multiple links to modify
by pressing Ctrl and clicking on the number of the link in the dialog. The following tools are available to
the selected links.
Save Location. Saves the new location of a linked instance.
Save Markups. Saves changes to imported DWF markups. For more information on imported markups,
see Linking DWF Markup Files
Remove. Removes the link from the project.
Reload From. Changes the path of the link if the linked file has been moved. See
Re-establishing Unresolved References
Unload. Removes the display of the linked model in the project but continues the link.
Description
Indicates the name of the file being linked.
Indicates whether the linked file is loaded
in the host model. The field will display as
Loaded, Not Loaded, or Not Found.
Determines whether this linked model will
be shown (Attachment) or hidden (Over-
lay) when the host file is linked into anoth-
er model. See Showing or Hiding Nested
Linked Revit Models on page 1279.
Indicates if the linked model's location is
saved in the shared coordinate system. See
Shared Positioning on page 1296 and
ing Named Locations on page 1296.
Size of the linked file.
Location of the linked model on your
computer. In worksharing, this is the loca-
tion of the central file.
Indicates whether the linked model's saved
path is relative or absolute. See
agement Options on page 1287.
Location of the linked model if it is a local
copy of a central file. For more information
on the central file and worksharing, see
Working in a Team on page 1249.
on page 1403.
on page 1286.
Defin-
Link Man-
Identifying and
Manage Links Dialog | 1287
