File Type
NOTE The type catalog must have exactly
the same name as its family RFA file. The
names are case-sensitive.
Lookup tables (CSV) that Revit MEP com-
ponents use to define instance parameters
Image Files (BMP, JPG, JPEG, or PNG) that
create a custom color, design, texture, or
bump map for a render appearance
Photometric data files (IES) for use with
lighting families

Sharing with Autodesk Seek

NOTE Autodesk Seek on page 108 is currently available only in the English edition of the software.
1 In the Family Editor, click
2 In the Share family with Autodesk Seek dialog, specify whether to share the current family or
browse for one, and click OK.
BEST PRACTICE Use the 3D view of the family. There should not be any dimensions, reference planes,
or lines visible in the preview.
3 In the Set OmniClass Code dialog, specify whether to apply an OmniClass code to your family
or continue with publishing.
If you select Apply an OmniClass code, the OmniClass Table 23 Product Classification dialog
displays, from which you assign a code that is appropriate for your content. Select a code, click
OK, and click Save to save the OmniClass code to your family.
Location
Windows XP: C:\Documents and Set-
tings\All Users\Application
Data\Autodesk\<Revit MEP release
name>\LookupTables
Windows Vista: C:\Program-
Data\Autodesk\<Revit MEP release
name>\LookupTables
Folders in the Revit Render Appearance
Library installed by default at:
Windows XP:C:\Program Files\Autodesk
<Revit release name>\Data\Render-
ing\assetlibrary_base.fbm
Windows Vista:C:\Program
Files\Autodesk <Revit release
name>\Data\Rendering\assetlib-
rary_base.fbm
Windows XP:C:\Documents and Set-
tings\All Users\Application
Data\Autodesk\<Revit release
name>\IES
Windows Vista:C:\Program-
Data\Autodesk\<Revit release
name>\IES
Publish Share with Autodesk Seek.
Publishing to Autodesk
®
Seek | 1383
