Design Options and Wall Joins

The cleanup of joins between walls in the main model and walls in the primary option works the same way
as when all walls are in the main model. To avoid incorrect wall joins between the main model and secondary
options, move the wall from the main model to the design option set. See Moving Elements from the Main
Model to a Design Option Set on page 1313.
Walls in the main model
A wall added in the primary option; join cleans up properly
A wall in a secondary option joined to the main model
To avoid the above problem with wall joins in a secondary option, add the horizontal wall to that option.
The wall join then cleans up properly, as shown. See Wall Joins on page 651.
