Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite 2010 User Manual page 1251

Property
Elevation
Arm Height
Tilt
Color Preview
Color
Office Clutter Properties
Property
Cast Reflections
Notebook Computer: The following properties display for notebook computers.
Open
Power
Custom Screen
Screen File Name
Picture Frame: The following properties display for picture frames.
Portrait
Stand
Frame Material
Use Custom Picture
Picture File Name
Description
Height setting for the seat of the chair. Select Low, Medium, or High.
Height setting for the arms of the chair. Select Low, Medium, or High.
Angle to tilt the back of the chair, based on the slider setting.
Image to use to preview the color for the object. Click
file.
Color of the object. Select a value from the list.
Description
Whether the rendered image shows a reversed, mirror reflection of the object on other
surfaces, such as glass. When this option is cleared, the rendered image shows a repeat
image in the reflecting surface instead of a reversed, mirror image. See
on page 1210.
How much to open the computer. Use the slider to close it or control its angle when
open.
Whether the notebook computer is turned on and can display an image.
Whether the computer screen displays a specified image when the computer is open
and turned on.
Custom image to display on the computer screen. Click
file. This image displays only when Power and Custom Screen are selected. See
Practice for Storing Image Files
Whether the frame is oriented in portrait mode (vertically). Clear this option to orient
the frame in landscape mode (horizontally).
Whether the frame leans on a stand. Clear this option if the frame hangs on a wall.
Material for the frame. Select a value from the list.
Whether an image displays in the picture frame when it is rendered.
Custom image to display in the picture frame when it is rendered. Click
navigate to the file. See Best Practice for Storing Image Files
Specifying a Render Appearance for an RPC Family | 1209
(Browse) to navigate to the
(Browse) to navigate to the
on page 519.
Cast Reflections
Best
(Browse) to
on page 519.
