Use the left pane to preview the 3D model that will be exported. Revit Architecture exports everything you
see in the preview pane to the ADSK file.
Under Messages, the number of model elements to export is displayed. If the number of model elements is
large, try simplifying the view again before exporting it. See
Use (Model Graphics Style),
site in the preview pane. See
For 3D View for Export, select a 3D view to be exported to the ADSK file.
The first time you open the Building Site Export Settings dialog, the active 3D view displays in the preview
pane, by default. If the active view is not a 3D view, the first 3D view in the 3D View for Export list displays.
Clicking Export or OK saves the dialog settings, so the next time you open the dialog, the settings will be
the same.
The right pane has the following tabs for reviewing the model elements in the preview panel.
Model. Displays the elements to be exported to the ADSK file. See
Building Site on page 1380.
Project Information. Displays information for the project. See
Building Site on page 1380.
Location. Displays the survey point in shared coordinates. See
Site on page 1381.
When you are satisfied with the settings, click Export to export the building site to an ADSK file.
(SteeringWheels), and
Specifying a Model Graphics Style
Simplifying the Model on page 1377.
(ViewCube) to view and navigate the building
on page 251 and SteeringWheels
Reviewing the Model Elements of a
Reviewing Project Information for the
Reviewing Location Settings for the Building
Exporting Building Sites | 1379
on page 225.
