Simplifying the Model
To create an efficient ADSK file
export only the relevant parts of the model (such as exterior walls and doors) and hide the rest. Do this by
applying the Export to Civil Engineering view template to the 3D view, as follows:
1 Set the Function parameter to Interior for non-essential walls, doors, stairs, floor, ramps, and
curtain walls.
NOTE The Function parameter must be set to interior for the Export to Civil Engineering view template
to work correctly.
2 In the 3D view, click View tab
template to current view.
3 In the Apply View Template dialog, select Export to Civil Engineering from the Names list.
NOTE If Export to Civil Engineering is not in the list, you need to update your project to the new
template by transferring project standards. See
4 In the Apply View Template dialog, apply addition visibility and graphic overrides by clicking
Edit under View Properties. See
5 Click OK.
The categories listed below are visible when the Export to Civil 3D view template is applied to the 3D model.
All other categories are not visible, including categories from other disciplines.
Areas
Columns
Curtain systems
Doors
Floors
Generic models
Mass
Parking
Plantings
Ramps
Roads
Roofs
Site
Stairs
Structural columns
Structural foundations
Structural framing
Walls
on page 1376 for opening in a civil engineering application, such as Civil 3D,
Graphics panel
Creating a View Template
View Templates drop-down
Transferring Project Standards
on page 507.
Exporting Building Sites | 1377
Apply new
on page 446.
