Graphics Issues; Images; Plotting - Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite 2010 User Manual

Reference planes, crop boundaries, and scope boxes are hidden for printing by default. To show them when
you print, click
crop boundaries, and scope boxes.
My reference planes are printing. I don't want them to print.
Click
Can the colors in a drawing be overridden so they print in solid black and white?
Click
menu.
This ensures that a black and white printer properly processes colors in a project. This option does not
produce grayscale. All colors are converted to black.
How do I increase print speed in elevation, section, and perspective views?
Be sure that the Far Clipping property is active for the view. Go to the view properties of the view, and select
an option for Far Clipping.
I choose black lines or gray scale in Revit Architecture, but my printer still prints in colors.
Some printer drivers override the Colors setting that you specified in Revit Architecture. To get the desired
color output, manually set the color through your printer s properties.

Graphics Issues

When I print, surface patterns are partially submerged into the concave side of a wall's surface.
Click

Images

The printed output of imported images is different than the on-screen display.
Click

Plotting

Problems printing raster images with a XES Synergix 8830 plotter.
In the properties dialog for the XES Synergix 8830, under the Graphics tab, there is a check box for Enable
RTL native mode resolution. Clear the check box, and the raster images should print correctly.
How do I plot to Reprodesk?
If the PRN file has been changed to a PLT file and the processing of the file still produces a black screen,
once the file has been sent to Reprodesk change the pen setting from standard (the default) to asinfile pen.
Other Plotting Considerations
Always use a color cartridge in the plotter when the Windows driver is set to use color mapping.
1412 | Chapter 25 Print Troubleshooting, Diagnostic Tools, and Error Handling
Print Print Setup. In the Print Setup dialog, clear the options for reference planes,
Print Print Setup. In the Print Setup dialog, select the Hide ref/work planes check box.
Print Print Setup. In the Print Setup dialog, select the Black Lines option from the Colors
Print Print Setup. In the Print Setup dialog, select the Vector Processing option.
Print Print Setup. In the Print Setup dialog, select the Raster Processing option.
