Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite 2010 User Manual page 1242

3 To add the lighting fixture to a light group, do the following:
4 To remove the lighting fixture from a light group, do the following:
Adding and Removing Lights in a Light Group Using the Artificial Lights
Dialog
1 Open the Artificial Lights dialog.
2 To add an individual lighting fixture to a light group, do the following:
3 To remove an individual lighting fixture from a light group, do the following:
4 When you are finished in the Artificial Lights dialog, click OK.
Adding and Removing Lights in a Light Group Using the Light Group Editor
1 Open the Light Group Editor, using either of the following methods:
1200 | Chapter 19 Rendering
a On the Options Bar, for Light Group, select the desired group.
If the light group does not yet exist, select Edit/New, and create a group. See
Light Group on page 1199.
b At the prompt, click OK.
a On the Options Bar, for Light Group, select None.
b At the prompt, click OK.
See Opening the Artificial Lights Dialog
a In the Artificial Lights dialog, under Ungrouped Lights, select the lighting fixture.
b Under Fixture Options, click Move to Group.
c In the Light Groups dialog, select the desired light group, and click OK.
In the Artificial Lights dialog, the selected lighting fixture displays under the selected light group
name.
a In the Artificial Lights dialog, under Grouped Lights, expand the light group name.
b Select the lighting fixture to remove from the group.
c Under Fixture Options, click Remove from Group.
In the Artificial Lights dialog, the selected lighting fixture displays under Ungrouped Lights.
In a project view, select a lighting fixture. On the Options Bar, for Light Group, click Edit.
NOTE If Light Group displays None, select the light group to which you want to add the selected
lighting fixture. Then click Edit.
Open the Artificial Lights
Group Options, click Edit.
Revit Architecture enters light group edit mode. The Light Group panel displays on the ribbon.
Model elements and lighting fixtures that belong to another light group display in halftone.
Lighting fixtures that belong to the selected light group display in green. Lighting fixtures that
are not currently assigned to a light group display normally.
on page 1199.
dialog. In the Artificial Lights dialog, select the group name. Under
Creating a
