Configuring Line Rate on
Physical Interface
To do...
Display the GTS information
on each interface
Configuration example for traffic shaping
Configure TS on the interface Ethernet1/0 to shape the traffic transmitted from
the interface (shaping the traffic exceeding 500 kbps).
# Enter system view.
<Sysname> system-view
# Enter interface view.
[Sysname] interface ethernet1/0
# Configure traffic shaping parameters.
[Sysname-Ethernet1/0] qos gts any cir 500

Configuring Line Rate on physical interface

You can limit the rate at which a physical interface sends out data.
Follow these steps to configure Line Rate on physical interface
To do...
Enter system view
Enter interface Enter interface
view or port view
group view
Enter port
group view
Configure interface LR
Traffic Policing and Traffic Shaping Configuration
Use the command...
display qos gts interface
[ interface-type
interface-number ]
Use the command...
system-view
interface interface-type
interface-number
port-group aggregation
agg-id
qos lr outbound cir
committed-information-rate
[ cbs committed-burst-size
[ ebs excess-burst-size ] ]
1637
Remarks
Optional
The display command can be
executed in any view
Remarks
-
Use either command
Configured in interface view,
the setting is effective only on
the current interface;
configured in port group
view, the setting is effective
on all the ports in the current
port group.
For the information about
port group configuration,
refer to "Link Aggregation
Configuration" on page 351.
Required
cbs is half of cir within unit
time by default. If the default
value is lower than 1875,
then 1875 is taken as the
default value.
ebs defaults to 0.
