1430 C 78: MPLS L2VPN C
HAPTER
Configuring a PE
Interface Connecting a
CE
Configuring a PE
Interface Connecting a
CE to Use PPP/HDLC/FR
ONFIGURATION
Enabling MPLS L2VPN
■
Follow these steps to complete the above two tasks:
To do...
Enter system view
Configure the LSR ID
Configure MPLS basic capability and enter
MPLS view
Return to system view
Enable MPLS L2VPN
MPLS L2VPN supports these types of interfaces: Ethernet interface/subinterface,
GE interface/subinterface, 10GE interface, Serial interface/subinterface (excluding
subinterfaces using FR as the link layer protocol), POS interface, VLAN interface,
and ATM interface/ subinterface.
n
MPLS L2VPN support of POS interfaces varies by device.
A PE interface connecting a CE can use these encapsulation types:
PPP
■
HDLC
■
FR
■
Ethernet
■
VLAN
■
ATM
■
Synchronous/asynchronous serial interfaces and POS interfaces can use the link
layer protocols of PPP, HDLC, and FR.
For configuration information about serial and POS interfaces, refer to
Interface Configuration" on page 99
83.
Configuring a PE interface connecting a CE to use PPP
Follow these steps to configure a PE interface connecting a CE to use PPP as the
encapsulation protocols:
To do...
Enter system view
Enter interface view
Configure the link layer
protocol
Use the command...
system-view
mpls lsr-id
mpls
quit
mpls l2vpn
and "POS Interface Configuration" on page
Use the command...
system-view
interface { serial | pos } number
link-protocol ppp
Remarks
-
Required
Required
-
Required
"WAN
Remarks
-
-
Optional
PPP by default
