Displaying and
Maintaining IPv6 PIM
IPv6 PIM
Configuration
Examples
IPv6 PIM-DM
Configuration Example
To do...
View the BSR information in
the IPv6 PIM-SM domain and
locally configured C-RP
information in effect
View the information of IPv6
unicast routes used by IPv6
PIM
View the number of IPv6 PIM
control messages
View the information about
unacknowledged graft
messages
View the IPv6 PIM information
on an interface or all
interfaces
View the information of
join/prune messages to send
View IPv6 PIM neighboring
information
View the content of the IPv6
PIM routing table
View the RP information
Reset IPv6 PIM control
message counters
Network requirements
Receivers receive VOD information through multicast. The receiver groups of
different organizations form stub networks, and at least one receiver host
exists in each stub network. The entire IPv6 PIM domain operates in the dense
mode.

Displaying and Maintaining IPv6 PIM

Use the command...
display pim ipv6 bsr-info
display pim ipv6 claimed-route
[ ipv6-source-address ]
display pim ipv6 control-message
counters [ message-type { probe |
register | register-stop } | [ interface
interface-type interface-number |
message-type { assert | bsr | crp | graft
| graft-ack | hello | join-prune |
state-refresh } ] * ]
display pim ipv6 grafts
display pim ipv6 interface
[ interface-type interface-number ]
[ verbose ]
display pim ipv6 join-prune mode
{ sm [ flags flag-value ] | ssm }
[ interface interface-type
interface-number | neighbor
ipv6-neighbor-address ] * [ verbose ]
display pim ipv6 neighbor [ interface
interface-type interface-number |
ipv6-neighbor-address | verbose ] *
display pim ipv6 routing-table
[ ipv6-group-address [ prefix-length ] |
ipv6-source-address [ prefix-length ] |
incoming-interface [ interface-type
interface-number | register ] |
outgoing-interface { include | exclude
| match } { interface-type
interface-number | register } | mode
mode-type | flags flag-value | fsm ] *
display pim ipv6 rp-info
[ ipv6-group-address ]
reset pim ipv6 control-message
counters [ interface interface-type
interface-number ]
1263
Remarks
Available in any
view
Available in any
view
Available in any
view
Available in any
view
Available in any
view
Available in any
view
Available in any
view
Available in any
view
Available in any
view
Available in use
view
