DHCP Test Configuration
Example
FTP Test Configuration
Example
Extend results:
Packet lost in test: 0%
Failures due to timeout: 0
Failures due to disconnect: 0
Failures due to no connection: 0
Failures due to sequence error: 0
Failures due to internal error: 0
Failures due to other errors: 0
Network requirements
Use the NQA DHCP function to test the time necessary for Router A to obtain an IP
address from the DHCP server Router B.
Network diagram
Figure 599 Network diagram for DHCP
NQA client
Eth1/0
10.1.1.1/16
IP network
Router A
Configuration procedure
# Create a DHCP test group and configure related test parameters.
<RouterA> system-view
[RouterA] nqa entry admin test
[RouterA-nqa-admin-test] type dhcp
[RouterA-nqa-admin-test-dhcp] operation interface ethernet 1/0
[RouterA-nqa-admin-test-dhcp] quit
# Enable the DHCP test.
[RouterA] nqa schedule admin test start-time now lifetime forever
# Display results of one DHCP test.
[RouterA] display nqa result admin test
NQA entry(admin admin, tag test) test results:
Send operation times: 1
Min/Max/Average round trip time: 624/624/624
Square-Sum of round trip time: 389376
Last succeeded probe time: 2007-03-14 17:47:29.3
Extend results:
Packet lost in test: 0%
Failures due to timeout: 0
Failures due to disconnect: 0
Failures due to no connection: 0
Failures due to sequence error: 0
Failures due to internal error: 0
Failures due to other errors: 0
Network requirements
Use the NQA FTP function to test the connection with a specified FTP server and
the time necessary for Device A to upload a file to the FTP server. The login
NQA Configuration Examples
DHCP server
Eth1/0
10 .2 .2.2/16
Router B
Receive response times: 1
