1328 C 76: MPLS B
HAPTER

Configuring MPLS LDP

Configuration
Prerequisites
MPLS LDP Configuration
Task List
Configuring MPLS LDP
Capability
C
ASICS ONFIGURATION
To do...
Configure a static LSP
taking the current LSR as
the egress
n
Support for the outgoing-interface interface-type interface-number keyword
■
and argument combination varies by device.
If you specify the next hop when configuring a static LSP, and the address of
■
the next hop is in the routing table, you must specify the next hop when
configuring the static IP route.
If you specify the outgoing interface for a static LSP, you must also specify the
■
outgoing interface when configuring the static IP route.
When configuring an ingress or transit LSR, the local public network address
■
cannot be specified as the next hop.
For information about configuring static IP route, refer to
■
Dynamic Routing" on page
Before configuring LDP, be sure to complete the following task:
Configuring MPLS basic capability
■
Complete these tasks to configure LDP:
Task
"Configuring MPLS LDP Capability" on page 1328
"Configuring Local LDP Session Parameters" on page 1329
"Configuring Remote LDP Session Parameters" on page 1329
"Configuring the Policy for Triggering LSP Establishment" on page 1330
"Configuring Label Advertisement, Distribution and Retention Modes" on
page 1331
"Configuring LDP Loop Detection" on page 1331
"Configuring LDP MD5 Authentication" on page 1331
"Enabling MTU Signaling" on page 1332
Follow these steps to enable MPLS LDP capability:
To do...
Enter system view
Enable LDP capability for the
current node and enter MPLS
LDP view
Configure the LDP LSR ID
Exit to system view
Use the command...
static-lsp egress lsp-name
incoming-interface interface-type
interface-number in-label in-label
817.
Use the command...
system-view
mpls ldp
lsr-id lsr-id
quit
Remarks
Optional
"Static Routing and
Remarks
Required
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Remarks
-
Required
Not enabled by default
Optional
MPLS LSR ID of the LSR by
default
-
