Troubleshooting Voip Configuration; Busy Tone Given Immediately After Number Dialed - 3Com MSR 50 Series Configuration Manual

Troubleshooting VoIP
Configuration
Busy Tone Given
Immediately after
Number Dialed
[RouterA-voice-dial-entity755] match-template 0755....
[RouterA-voice-dial-entity755] address ip 2.2.2.2
# Enable fast connection, tunnel function and H.255 out-of-band DTMF
transmission for the VoIP entity.
[RouterA-voice-dial-entity755] fast-connect
[RouterA-voice-dial-entity755] tunnel-on
[RouterA-voice-dial-entity755] outband h245
[RouterA-voice-dial-entity755] quit
# Configure the local interface and phone number for Telephone A.
[RouterA-voice-dial] entity 1001 pots
[RouterA-voice-dial-entity1001] match-template 0101001
[RouterA-voice-dial-entity1001] line 1/1
# Enable H.225 out-of-band DTMF transmission for the POTS entity.
[RouterA-voice-dial-entity1001] outband h225
2 Configure Router B
# Configure the VoIP entity.
<RouterB> system-view
[RouterB] voice-setup
[RouterB-voice] dial-program
[RouterB-voice-dial] entity 010 voip
[RouterB-voice-dial-entity10] match-template 010....
[RouterB-voice-dial-entity10] address ip 1.1.1.1
# Enable out-of-band DTMF transmission for the VoIP entity.
[RouterB-voice-dial-entity10] outband h225
[RouterB-voice-dial-entity10] quit
# Configure the local interface and phone number for Telephone B.
[RouterB-voice-dial] entity 2001 pots
[RouterB-voice-dial-entity2001] match-template 07552001
[RouterB-voice-dial-entity2001] line 1/1
# Enable out-of-band DTMF transmission for the POTS entity.
[RouterB-voice-dial-entity2001] outband h225
Symptom
Busy tone is given immediately after a number is dialed.

Troubleshooting VoIP Configuration

2285
