1192 C 71: PIM C
HAPTER
Configuring Join/Prune
Message Limits
Displaying and
Maintaining PIM
ONFIGURATION
A larger join/prune message size will result in loss of a larger amount of
information when a message is lost; with a reduced join/message size, the loss of a
single message will bring relatively minor impact.
By controlling the maximum number of (S, G) entries in a join/prune message, you
can effectively reduce the number of (S, G) entries sent per unit of time.
Follow these steps to configure join/prune message limits:
To do...
Enter system view
Enter public instance PIM view
or VPN instance PIM view
Configure the maximum size
of a join/prune message
Configure the maximum
number of (S, G) entries in a
join/prune message
To do...
View the BSR information in
the PIM-SM domain and
locally configured C-RP
information in effect
View the information of
unicast routes used by PIM
View the number of PIM
control messages
View the information about
unacknowledged graft
messages
View the PIM information on
an interface or all interfaces
View the information of
join/prune messages to send
View PIM neighboring
information
Use the command...
system-view
pim [ vpn-instance
vpn-instance-name ]
jp-pkt-size packet-size
jp-queue-size queue-size
Use the command...
display pim [ vpn-instance
vpn-instance-name | all-instance ]
bsr-info
display pim [ vpn-instance
vpn-instance-name | all-instance ]
claimed-route [ source-address ]
display pim [ vpn-instance
vpn-instance-name | all-instance ]
control-message counters
[ message-type { probe | register |
register-stop } | [ interface
interface-type interface-number |
message-type { assert | bsr | crp |
graft | graft-ack | hello | join-prune |
state-refresh } ] * ]
display pim grafts
display pim interface [ interface-type
interface-number ] [ verbose ]
display pim [ vpn-instance
vpn-instance-name | all-instance ]
join-prune mode { sm [ flags
flag-value ] | ssm } [ interface
interface-type interface-number |
neighbor neighbor-address ] *
[ verbose ]
display pim [ vpn-instance
vpn-instance-name | all-instance ]
neighbor [ interface interface-type
interface-number | neighbor-address |
verbose ] *
Remarks
-
-
Optional
8,100 bytes by default
Optional
1,020 by default
Remarks
Available in any
view
Available in any
view
Available in any
view
Available in any
view
Available in any
view
Available in any
view
Available in any
view
