Configuring the SNMP
Test
To do...
Configure the interval for
sending consecutive packets
Configure the timeout time in
a UDP-jitter test
Configure the source IP
address of a probe request in
a test operation
Configure common optional
parameters
The number of probes made in a UDP-jitter test depends on the probe count
command, while the number of probe packets sent in each probe depends on the
probe packet-number command.
The SNMP query test is used to test the time the NQA client takes to send an
SNMP query packet to the SNMP agent and then receive a response packet.
Configuration prerequisites
The SNMP agent function must be enabled on the device serving as an SNMP
agent before the SNMP test. For the configuration of SNMP agent, refer to "SNMP
Configuration" on page 2085.

Configuring the SNMP test

Follow these steps to configure the SNMP test:
To do...
Enter system view
Enter NQA test group view
Configure the test type as
SNMP and enter test type
view
Configure the destination
address for a test operation
Specify the source port
number for a probe request in
a test operation
Configuring an NQA Test Group
Use the command...
probe packet-interval
packet-interval
probe packet-timeout
packet-timeout
source ip ip-address
Refer to "Configuring
Optional Parameters Common
to an NQA Test Group" on
page 2028
Use the command...
system-view
nqa entry admin-name
operation-tag
type snmp
destination ip ip-address
source port port-number
2023
Remarks
Optional
20 milliseconds by default.
Optional
3000 milliseconds by default.
Optional
By default, no source IP
address is specified.
The source IP address must be
that of an interface on the
device and the interface must
be up. Otherwise, the test will
fail.
Optional
Remarks
-
-
Required
Required
By default, no destination IP
address is configured for a
test operation.
Optional
By default, no source port
number is specified.
