1434 C 78: MPLS L2VPN C
HAPTER
Configuration
Prerequisites

Configuration Procedure

Configuring Martini
MPLS L2VPN
Configuration
Prerequisites
ONFIGURATION
Before configuring SVC MPLS L2VPN, complete these tasks:
Configuring IGP on the PEs and P devices to guarantee the IP connectivity of
■
the MPLS backbone
Configuring MPLS basic capability and MPLS LDP for the MPLS backbone on
■
the PEs and P devices to establish LDP LSPs
Enabling MPLS L2VPN on the PEs
■
For VLAN access, configuring a subinterface; for ATM access, configuring a VC
■
Establishing the tunnels between PEs according to the tunneling policy.
■
To configure SVC MPLS L2VPN, you need the following data:
Types and numbers of the interfaces connecting the CEs
■
Destination LSR ID of SVC
■
Incoming and outgoing labels of the L2VPN connection
■
SVC tunneling policy
■
Follow these steps to configure SVC MPLS L2VPN on the PE:
To do...
Enter system view
Enter interface view for the
interface connecting the CE
Create an SVC MPLS L2VPN
connection
Martini MPLS L2VPN uses extended LDP to transfer Layer 2 information and VC
labels.
Before configuring Martini MPLS L2VPN, complete these tasks:
Configuring IGP on the PEs and P devices to guarantee the IP connectivity of
■
the MPLS backbone
Configuring MPLS basic capability and MPLS LDP for the MPLS backbone on
■
the PEs and P devices to establish LDP LSPs
Enabling MPLS L2VPN on the PEs
■
Establishing remote LDP sessions between PEs
■
For VLAN access, configuring a subinterface; for ATM access, configuring a VC
■
To configure Martini MPLS L2VPN, you need the following data:
Types and numbers of the interfaces connecting the CEs
■
L2VC destination address and VC ID
■
Use the command...
system-view
interface interface-type
interface-number
mpls static-l2vc destination
destination-router-id
transmit-vpn-label
transmit-label-value receive-vpn-label
receive-label-value [ tunnel-policy
tunnel-policy-name ] [ control-word |
no-control-word ]
Remarks
-
-
Required
