Configuring the DLSw
Test
VERVIEW
To do...
Configure the destination
address for a test operation
Configure the destination
port
Configure the size of probe
packets sent
Configure the string of fill
characters of a probe packet
sent
Specify a source port number
for a probe request in a test
operation
Configure the source IP
address of a probe request in
a test operation
Configure common optional
parameters
The DLSw test is used to test the response time of the DLSw device.
Configuration prerequisites
Enable the DLSw function on the peer device before DLSw test. For the
configuration of DLSw, refer to "DLSw Configuration" on page 211.

Configuring the DLSw test

Follow these steps to configure the DLSw test:
To do...
Enter system view
Use the command...
destination ip ip-address
destination port
port-number
data-size size
data-fill string
source port port-number
source ip ip-address
Refer to "Configuring
Optional Parameters Common
to an NQA Test Group" on
page 2028
Use the command...
system-view
Remarks
Required
By default, no destination IP
address is configured for a
test operation.
The destination address must
be the IP address of the
listening service configured on
the NQA server.
Required
By default, no destination port
number is configured for a
test operation.
The destination port number
must be the port number of
the listening service
configured on the NQA
server.
Optional
100 bytes by default.
Optional
The string of fill characters of
an ICMP probe packet is the
string corresponding with the
ASCII code 00 to 09 by
default.
Optional
By default, no source port
number is specified.
Optional
By default, no source IP
address is specified.
The source IP address must be
that of an interface on the
device and the interface must
be up. Otherwise, the test will
fail.
Optional
Remarks
-
