1372 C 77: MPLS TE C
HAPTER
Tuning MPLS TE
Tunnel Setup
Configuration
Prerequisites
Configuration
Procedures
ONFIGURATION
To do...
Enter system view
Enter interface view of MPLS
TE link
Assign the link to a link
administrative group
Exit to system view
Enter MPLS TE tunnel
interface view
Configure the affinity
attribute of the MPLS TE
tunnel
Submit current tunnel
configuration
Configuring CR-LSP reoptimization
Dynamic CR-LSP optimization involves periodic calculation of paths that traffic
trunks should traverse. If a better route is found for an existing CR-LSP, a new
CR-LSP will be established to replace the old one, and services will be switched to
the new CR-LSP.
Follow these steps to configure CR-LSP reoptimization:
To do...
Enter system view
Enter MPLS TE tunnel interface
view
Enable reoptimization for the
MPLS TE tunnel
Submit current tunnel
configuration
Exit to user view
Perform reoptimization on all
MPLS TE tunnels with
reoptimization enabled
This section only covers the configuration tasks for tuning MPLS TE tunnel setup.
The configurations described in this section need to be used together with the
dynamic signaling protocol CR-LDP or RSVP-TE.
Before performing them, be aware of each configuration objective and its impact
on your system.
Tuning MPLS TE tunnel setup involves these tasks:
"Configuring loop detection" on page 1373
■
Use command to...
system-view
interface interface-type
interface-number
mpls te link administrative
group value
quit
interface tunnel
tunnel-number
mpls te affinity property
properties [ mask
mask-value ]
mpls te commit
Use command to...
system-view
interface tunnel
tunnel-number
mpls te reoptimization
[ frequency seconds ]
mpls te commit
return
mpls te reoptimization
Remarks
--
--
Optional
The default is 0x00000000.
--
--
Optional
The default affinity attribute is
0x00000000, and the default
mask is 0x00000000.
Required
Remarks
--
--
Required
Disabled by default
Required
--
Optional
