2016 C 109: NQA O
HAPTER

NQA Test Operation

NQA Configuration
Task List
Configuring the NQA
Server
VERVIEW
After you create a test group and enter the test group view, you can configure
related test parameters. Test parameters vary with the test type. For details, see the
configuration procedure below.
To perform an NQA test successfully, perform the following configurations on the
NQA client:
1 Enable the NQA client;
2 Create a test group and configure test parameters according to the test type;
3 Perform the NQA test through the related enable commands;
4 View test results using the display or debug commands.
For TCP, UDP-jitter or UDP-echo tests, you need to configure the NQA server on
the peer device.
Complete these tasks to configure NQA.
Task
"Configuring the NQA Server" on page 2016
"Enabling the NQA Client" on page 2017
"Creating an NQA Test Group" on page 2017
"Configuring an NQA Test
Group" on page 2017
"Configuring the Collaboration Function" on page 2027
"Configuring Trap Delivery" on page 2027
"Configuring Optional Parameters Common to an NQA Test
Group" on page 2028
"Scheduling an NQA Test Group" on page 2029
Before performing TCP, UDP-echo or UDP-jitter tests, you need to configure the
NQA server on the peer device. The NQA server makes a response to the requests
"Configuring the ICMP-echo
Test" on page 2017
"Configuring the DHCP Test"
on page 2019
"Configuring the FTP Test" on
page 2019
"Configuring the HTTP Test"
on page 2020
"Configuring the UDP-jitter
Test" on page 2021
"Configuring the SNMP Test"
on page 2023
"Configuring the TCP Test"
on page 2024
"Configuring the UDP-echo
Test" on page 2025
"Configuring the DLSw Test"
on page 2026
Remarks
Required for TCP, UDP-echo
and UDP-jitter tests
Optional
Required
Use any of the approaches.
Optional
Optional
Optional
Required
